Product Description

Covers the absolute and differential pressure ranges of typical air data instruments.

  • Fixed wing and rotary wing range versions
  • True Pt, Ps, Qc operation
  • Transfer standard level measurement uncertainty
  • Automated rate measurement with user specified sample time
  • Automated leak check function
  • Compact and rugged presentation
  • SDS self defense system shuts off test ports to protect from overpressure
  • RS232 and IEEE-488 interfaces included
  • Battery pack available
  • Ideal for validation of air data test sets (ADTS)

RPM4-AD Air data version
RPM4-AD is a specific configuration of the RPM4 reference pressure monitor that measures and displays altitude (ft, m), airspeed units (kts, mph, km/h, Mach) and in conventional pressure units.
